Glazing
Omicron
Standard double glazing option, forming minimal profiles and providing maximum comfort.
Ωmega
An advanced triple glazing system taking thermal performance to the maximum.
Specifications
Max. Leaf weight
Depending on the number of wheels
=1000 kg (2205 lb)
=1000 kg (2205 lb)
Max. sliding leaf area
12 m2 (129 sqft)
16 m2(172 sqft)
Max. fix leaf area
19,5 m2 (210 sqft)
21 m2 (226 sqft)
Glass thickness
30-36 mm (1 3/16” - 1 7/16”)
46 - 54 mm (1 13/16” - 2 1/8”)
Installation flush to the ceiling / floor
Yes
Yes
Certificates
UW Values
Down to 1.2 W/m2K (0.21 Btu/hft2F)
down to 1.2 W/m2K (0.21 Btu/hft2F)
Resistance to Rain Penetration
EN 12208 : 1999, Class 8A
EN 12208 : 1999, Class E1050
Sound insulation
up to 42 dB, EN ISO 717-1:2013
up to 46 dB, EN ISO 717-1:2013
Air permeability
EN 12210 :1999, Class C5
EN 12210 : 1999, Class C5
Resistance to burglary
EN 1627:2011 RC 2 / RC 2 N
EN 1627:2011 RC 2 / RC 2 N
